Fɛn dilannenw ɲɛfɔli

NS-P148 Network Speaker Amplifier ye fanga caman sɔrɔcogo ye min dabɔra IP fɔlikan ni foroba ladɛrɛsi sigidabaw kama. A bɛ ni izini dual-core ARM + DSP chipset ye, a bɛ decoding baarakɛcogo sabatilen di ani ka réseau mankan cicogo ɲuman di hali ni doni girinman don. I n’a fɔ Réseau Speaker Amplifier, a ka ɲi kosɛbɛ sigidaw la minnu ka gɛlɛn i n’a fɔ bolifɛnw jɔyɔrɔw, izinibaw, ani jagokɛyɔrɔbaw.

A bɛ fɛn dɔ di min bɛ mɔgɔ kabakoya480W bɔliseko la, NS-P148 bɛ dɛmɛ don kumakanfɔlaw bilali ma minnu ka ca -densiti caman na 100V layini walima low-impedance bɔli fɛ. Nin pa kumakanfɔlan barikama in bɛ dakunba ni mankan tansiyɔn barikama sabati k’a sɔrɔ a bɛ mankan dɔgɔyali ni mankan dɔgɔya cogoyaw mara. Bas ni treble controls minnu bɛ se ka ladilan, olu bɛ sira di fine-tuning ma mankan sigida danfaralenw kama.

A dabɔra ni sistɛmu dannaya ye a hakili la, Réseau Speaker Amplifierbɛ SIP protocole dɛmɛani rezow kumaɲɔgɔnya sariya caman, minnu bɛ se ka kɛ sababu ye ka jɛɲɔgɔnya kɛ ni SIP PBX sitɛmuw ni kunnafonidilanw ye minnu bɛ cɛmancɛ la. Lakanali sɛrɛkiliw jɛlenw ani tilancɛ-rack chassis barikama b’a kɛ kɔkolo ye min bɛ se ka da a kan cidenyabaara-critical IP Paging Amplifier ani audio broadcasting systems belebelebaw-scale.

Fɛn kolomaw

● Sebaaya 480W dilancogo min ka bon-rezo kumakanfɔlaw sitɛmu belebelebaw kama

● Industri-grade fila-core ARM + DSP baarakɛyɔrɔ

● A bɛ SIP Paging Amplifier ni IP-based PA architectures dɛmɛ

● 100V ani 8Ω kumakanfɔlanw bɔli walasa ka sistɛmu dilancogo sɛgɛsɛgɛ

● THD dɔgɔya, mankan ka dɔgɔn walasa ka mankan jɛlen bɔ

● Kuran ni funteni lakanani fɛɛrɛ bɛɛ lajɛlen

Kɛrɛnkɛrɛnnenya la

Mɔdɛli	NS-P148 ye
Rated Power ka 8ohm	2×240W
Bridged Power ka 100V	480W
Seko ni dɔnko Taamacogo	588W
Réseau ka kumaɲɔgɔnya protocole	SIP, HTTP, HTTPS, IPv4, TLS, RTSP, RTP, RTCP, DHCP, DNS, NTP, TCP, UDP, IGMP, ICMP, ARP
Réseau Interface (Jɛkulu min bɛ wele ko Interface).	10/100Basi-TX,RJ45. Bamako, Mali
Decode (Dɛkodɔn) kɛli	OPUS, G722, G711U, G711A
Donanw ka sɛgɛsɛgɛli / Impedance	-0dBu/10kohm Balanbaliya / Balanbaliya
Kuran sɛnɛcogo Voltage	AC 100-120V, 50/60Hz walima AC220-240V, 50/60Hz
Kumafɔla bɔli	100V / 8Ω
Jaabi min bɛ kɛ tuma caman na	80Hz ~ 17KHz (+1dB /-3dB) Bamako, Mali.
S/N Ratiyo ye	>80dB (ni A-Gɛlɛya ye) .
T.H.D	<1% (at rated power, 1kHz)
Baarakɛyɔrɔ Nɛnɛ	90%
Ton Contrôles (Tonw) Kɔrɔsili	Basi:100Hz (± 10dB), Treble: 10KHz (± 10dB) Bamako, Mali.
Baarakɛyɔrɔ funteni	0 degere ~+40 degere
Fɛn dilannenw hakɛ (W×H×D) .	21544330 mm (Tila-Rack)
Kisɛya jɛlen	Kilo 3,3 ye
